Materials
Photoresist of 3D micro-nano size
Category:
Products
Keywords:
3D Micro-Nano Dimension Photoresist
We commit to developing high-performance photoresist and more processing solutions, and have successfully developed a series of photoresist products. The products have advantages such as high spatial resolution, nanometer-level line width, high light transmittance, excellent oxidation resistance and mechanical properties, and can be widely used in fields such as optical waveguides, microlenses, microfluidics, metamaterials and biomedicine.
| Two-photon photoresist |
Category | ProductModel | Key Features of Photoresist Products | Two-photonoperational wavelength range | Application Fields |
| Micro/NanoStructures | MAZ-8021 | High resolution、Igh modulus、Low shrinkage、Overhang design、Removable | 515nm | High-precision nanostructures、Lift-off process | |
| MAE-1008 | High resolution、Excellent mechanical properties | 515nm | Nano-scale micro-nano structure printing、Three-dimensional scaffold、Micro-nano robot | ||
| ATE-DIP | Refractive index matching glass substrate、High mechanical strength | 515/780nm | Materials engineering、Micro-optics、Integrated Optoelectronics、Microchannel | ||
| MTI-1009 | Structures with flexibility and high elasticity、Complex three-dimensional structures、Overhang design | 515nm | Submicron-level ultra-tough structure printing | ||
| MCP-7001 | Photochromism | 515nm | Micro-nano light-shielding material | ||
| MON-1015 | Photoresist with High Mechanical Strength, Stability & Low Shrinkage | 780nm | Microlens、Microlens array、Microfluidics、Microelectronics field | ||
| biocompatibility | BIO-MTI1010 | Compliant with GB厂16886.5-2017/S0 10993-5requirements,featuring biocompatibility, non-toxicity, and low autofluorescence under call microscopy | 515nm | Multicellular Scaffold、Tissue engineering、Biomedical device Life science、Mechanical metamaterial |
|
| BIO-HYD1001 | Hydrogel with Biocompatibility | 780nm | Biocompatible hydrogel、In vitro cell culture、Micron-scale cell growth scaffold | ||
| High Thermal Stability | MON-1009 | High-Temperature Resistant Photoresist with High Aspect Ratio & Low Shrinkage | 515nm | Grating、Optical waveguide、Micro-nano optics、Optical couplers and connectors |
Key Features
➤ High resolution, nanoscale micro-nano structureprocessing
➤ Low fluorescence, non-cytotoxicity
➤ Refractive index matching, excellent optical properties
➤ High temperature resistance, sub-micron bracket
➤ Super flexible, mechanical metamaterial
➤ High light transmittance, microlens, optical waveguide
➤ High reactivity, ultra-high speed micro and nano processing
➤ Green and environmentally friendly, solvent-free, no pre-treatment, simple operation
Applications
Customer Service
➤ Pre-sales customized service
We offer professional solutions according to customer processing needs; provide post-application expansion, reserved hardware and software interfaces.
➤ Technical service support
We provide hotline, remote control and on-site support; Provide users performance optimization, daily maintenance, parts replacement, application expansion and upgrade of the system.
➤ Lifetime application support
We provide free software upgrade, provide support such as test schemes, application operations, result analysis, and provide maintenance and solutions for common faults.
➤ Lifetime maintenance support
Equipped with professional maintenance engineers, 2 hours response, 72 hours to arrive at the scene.We provide extended warranty service, free training and lifetime maintenance.
